Processor

Intel® 2-core, 2.2GHz

Operating System

Microsoft^® Windows^® 2019, 2016 and 2012 R2, RHEL 8.0, 7.4, 6.9, SLES 12.3, VMware^® 6.7 U2, 6.5, 6.0, Microsoft Hyper-V^®, Citrix XenServer 7.1.0, 7.6.0

Physical

Storage Enclosure Weight (Maximum):
ME4012: 32 kg (71 lbs)
ME4024: 30 kg (66 lbs)
ME4084: 135 kg (298 lbs)

Storage Enclosure Height:
ME4012: 8.79 cm (3.46 inches)
ME4024: 8.79 cm (3.46 inches)
ME4084: 22.23 cm (8.75 inches)

Storage Enclosure Width:
ME4012: 44.3 cm (17.44 inches)
ME4024: 44.3 cm (17.44 inches)
ME4084: 44.45 cm (17.50 inches)

Storage Enclosure Depth:
ME4012: 57.6 cm (22.71 inches)
ME4024: 57.6 cm (22.71 inches)
ME4084: 89.22 cm (35.12 inches)

Power

Storage Enclosures:
ME4012: 580W, 1980 BTU, 100-240 VAC, 7.6-3.0A (x2), 50/60 Hz
ME4024: 580W, 1980 BTU, 100-240 VAC, 7.6-3.0A (x2), 50/60 Hz
ME4084: 2200W, 7507 BTU, 200-240 VAC, 11.07-9.23A (x2), 50/60 Hz

Expansion Enclosures:
ME412: 580W, 1980 BTU, 100-240 VAC, 7.6-3.0A (x2), 50/60 Hz
ME424: 580W, 1980 BTU, 100-240 VAC, 7.6-3.0A (x2), 50/60 Hz
ME484: 2200W, 7507 BTU, 200-240 VAC, 11.07-9.23A (x2), 50/60 Hz

Management

PowerVault Manager HTML5 GUI, OME 3.2, CLI, REST

Drive Bays

ME4012: 2/264
ME4024: 2/276
ME4084: 28/336

Connectivity

16Gb Fibre Channel
10Gb iSCSI
12Gb SAS
Multiprotocol: 16Gb Fibre Channel SFP+ / 10Gb iSCSI SFP+

Media Types

NLSAS: 7.2K 3.5″ – 4TB, 8TB, 10TB, 12TB, 12TB SED
NLSAS: 7.2K 2.5″ – 2TB, 2TB SED
SAS: 10K 2.5″ – 1.2TB, 1.8TB, 2.4TB, 2.4TB SED
SAS: 15K 2.5″ – 900GB, 900GB SED
SSD: 480GB, 960GB, 1.92TB, 1.92TB SED, 3.84TB
SDD / HDD: FIPS-certified SEDs

Software

PowerVault ME4 Series provides simplified, all-inclusive software licensing, including:
– ADAPT (Distributed RAID): (like Dynamic Disk Pooling) reduces drive rebuild times
– Thin Provisioning: Allocate and consume physical storage capacity as needed in disk pools. Thin is virtual mode only.
– SSD Read Cache: Increase execution speed of applications by caching previously read data
– IP & FC Remote Replication: Safely replicate data to any global location that includes mirroring thin provisioned pools
– Snapshots: Easily recover files after accidental deletion or alteration with Redirect on Write snaps
– 3 Level Tiering: Get great performance with less hardware expense
– Volume Copy/Clones: Enable seamless volume relocation and disk-based backup and recovery with a full, replicated copy of source data
– Encryption (SEDs): Render data useless to unauthorized users with drive-level encryption, even if the drive has been removed from the enclosure (internal key management included)
– Virtualization Integrations: VMware vSphere, vCenter SRM, Microsoft Hyper-V
– SupportAssist: Provides enhancements enabling automated maintenance capabilities

Expansion Capacity

ME412: 2U 12 x 3.5″ drive bays (12Gb SAS)
ME4024: 2U 24 x 2.5″ drive bays (12Gb SAS)
ME4084: 5U 84 x 3.5″ drive bays (12Gb SAS)

Network and Expansion I/O

All-in-one (single/dual controllers, internal drive bays, networking) with expansion options
ME4012: 2U 12 x 3.5” drive bays (2.5” drive carriers supported)
ME4024: 2U 24 x 2.5” drive bays
ME4084: 5U 84 x 3.5” drive bays (2.5” drive carriers supported)
