Description
Product specifications
Operating system
Windows 10 Pro
Windows 10 Home
Processor
Intel® Celeron® G4930 Processor (3.2GHz, 2MB Cache, 2400MHz, 2 core, 54W) + Intel® UHD Graphics 610
Intel® Pentium® Gold G5420 Processor (3.8GHz, 4MB Cache, 2400MHz, 2 core, 54W) + Intel® UHD Graphics 610
Intel® Pentium® Gold G5600 Processor (3.9GHz, 4MB Cache, 2400MHz, 2 core, 54W) + Intel® UHD Graphics 630
Intel® Core™ i3-9100 Processor (3.6GHz, up to 4.2 w/Boost, 6MB Cache, 2400MHz, 4 core, 65W) + Intel® UHD Graphics 630
Intel® Core™ i3-9300 Processor (3.7GHz, up to 4.3 w/Boost, 8MB Cache, 2400MHz, 4 core, 65W) + Intel® UHD Graphics 630
Intel® Core™ i5-9500 Processor (3.0GHz, up to 4.4GHz w/Boost, 9MB Cache, 2666MHz, 6 core, 65W) + Intel® UHD Graphics 630
Intel® Core™ i5-9600 Processor (3.1GHz, up to 4.6GHz w/Boost, 9MB Cache, 2666MHz, 6 core, 65W) + Intel® UHD Graphics 630
Intel® Core™ i7-9700 Processor (3.0GHz, up to 4.7GHz w/Boost, 12MB Cache, 2666MHz, 8 core, 65W) + Intel® UHD Graphics 630
Intel® Core™ i9-9900 Processor (3.1GHz, up to 5.0GHz w/Boost, 2666MHz, 16MB cache, 8 core) + Intel® UHD Graphics 630
Intel® Optane™ memory
16 GB Intel® Optane™ Memory (optional)
ENERGY STAR
ENERGY STAR Qualified Configuration
Chassis
65W Non-touch Chassis
65W Touch Chassis
Memory
4 GB (1 x 4 GB) DDR4-2666 SODIMM Memory
8 GB (1 x 8 GB) DDR4-2666 SODIMM Memory
8 GB (2 x 4 GB) DDR4-2666 SODIMM Memory
16 GB (1 x 16 GB) DDR4-2666 DIMM Memory
16 GB (2 x 8 GB) DDR4-2666 SODIMM Memory
32 GB (1 x 32 GB) DDR4-2666 SODIMM Memory
32 GB (2 x 16 GB) DDR4-2666 SODIMM Memory
64 GB (2 x 32 GB) DDR4-2666 SODIMM Memory
Internal M.2 storage
128 GB M.2 PCIe NVMe TLC SSD
256 GB Intel® Optane™ Memory H10 with SSD
512 GB Intel® Optane™ Memory H10 with SSD
256 GB M.2 PCIe NVMe TLC SSD
256 GB M.2 PCIe NVMe OPAL 2 Self-Encrypted (SED) TLC SSD
512 GB M.2 PCIe NVMe TLC SSD
512 GB M.2 PCIe NVMe OPAL 2 Self-Encrypted (SED) TLC SSD
1 TB M.2 PCIe NVMe TLC SSD
Internal storage
500 GB 7200 RPM SATA 2.5″ HDD
500 GB 7200 RPM SATA OPAL 2 Self-Encrypted (SED) 2.5″ HDD
500 GB 7200 RPM FIPS 140-2 2.5″ HDD
1 TB 7200 RPM SATA 2.5″ HDD
2 TB 5400 RPM SATA 2.5″ HDD
256 GB SATA TLC 2.5″ SSD
256 GB SATA OPAL 2 Self-Encrypted (SED) TLC 2.5″ SSD
256 GB FIPS 140-2 Self-Encrypted (SED) 2.5″ SSD
512 GB SATA TLC 2.5″ SSD
512 GB SATA OPAL 2 Self-Encrypted (SED) TLC 2.5″ SSD
512 GB FIPS 140-2 Self-Encrypted (SED) 2.5″ 2nd SSD
Drive bays internal
One 2.5″
Additional networking options
Intel® Wireless-AC 9560 (2×2) + Bluetooth® 5 (no-vPro™)
Intel® Wireless-AC 9560 (2×2) + Bluetooth® 5 (vPro™)
Power supply
120 Watt External Power Supply
Display
21.5″ diagonal FHD IPS widescreen LCD anti-glare WLED-backlit (1920 x 1080); 21.5″ diagonal FHD IPS widescreen LCD anti-glare WLED-backlit touch screen (1920 x 1080)
Webcam
No Integrated Webcam
1 MP HD webcam with integrated dual array digital microphone, maximum resolution of 1280 x 720
External I/O Ports
Side:
1 headphone/microphone combo;
1 SD 3.0 card reader;
1 SuperSpeed USB 5Gbps signaling rate;
1 SuperSpeed USB 5Gbps signaling rate (charging);
1 USB 2.0 Type-C®
Rear:
1 DisplayPort™ 1.2;
1 power connector;
1 RJ-45;
2 SuperSpeed USB 5Gbps signaling rate
Memory slots
2 SODIMM
Dimensions (W X D X H)
19.26 x 8.21 x 14.32 in
Weight
12.74 lb
