Chassis

Form Factor: 2U Rack Mount
Height: 86.9 mm (3.42 inch)
Width: 482.5 mm (19.00 inch)
Depth: 480.7 mm (18.93 inch) including bezel
Weight: 8.3 Kg (18.4 lbs)

Tool-less
LED for fan status
Power on/off switch

Drive Controllers

6Gb SAS HBA for PowerEdge 12th generation servers
12Gb SAS for PowerEdge 13th generation servers

Environmental Operating Conditions

Operating Temperature: 50 to 100.4 degrees F, 10 to 38 degrees C
Non-Operating Temperature (short term/archival): 16 to 35 degrees C (60.8 to 95 degrees F)/16 to 25 degrees C (60.8 to 77 degrees F)
Operating Humidity: 20 to 80% non-condensing
Non-Operating Humidity (short term/archival): 20 to 80%/20 to 50% non-condensing

Hard Drive

LTO-8

Native Capacity: 12TB*
Native performance: 300MB/s
Media used: LTO8
BackRead compatible: LTO7
Interface: SAS

LTO-7

Native Capacity: 6TB*
Native performance: 300MB/s
Media used: LTO7
BackRead compatible: LTO6, LTO5
Interface: SAS

LTO-6

Native Capacity: 2.5TB*
Native performance: 160MB/s
Media used: LTO6
BackRead compatible: LTO5, LTO4
Interface: SAS

Media Types

LTO

Power

Power Requirements: 100-127 VAC

Power Consumption: Up to 85W with two drives in operation
